IR3567B

IR3567B
Infineon Technologies
Dual Output Digital Multi-Phase Controller
Package Type: QFN 7 mm x 7 mm

Wir können den Controller entsprechend Ihrer Grafikkarte programmieren. Nach Auswahl der Option "Firmware" geben Sie bitte das genaue Modell Ihres Gerätes an, bevor Sie die Zahlung abschließen!

The IR3567B is a dual-loop digital multi-phase buck controller designed for CPU voltage regulation and is fully compliant with AMD® SVI1 & SVI2 and Intel© VR12 & VR12.5 specifications. The IR3567B includes IR’s Efficiency Shaping Technology to deliver exceptional efficiency at minimum cost across the entire load range. IR Variable Gate Drive optimizes the MOSFET gate drive voltage based on real-time load current. IR’s Dynamic Phase Control adds/drops active phases based upon load current and can be configured to enter 1-phase operation and diode emulation mode automatically or by command. IR’s unique Adaptive Transient Algorithm (ATA), based on proprietary non-linear digital PWM algorithms, minimizes output bulk capacitors and Multiple Time Programmable (MTP) storage saves pins and enables a small package size. Device configuration and fault parameters are easily defined using the IR Digital Power Design Center (DPDC) GUI and stored in onchip MTP. The IR3567B provides extensive OVP, UVP, OCP and OTP fault protection and includes thermistor based temperature sensing with VRHOT signal. The IR3567B includes numerous features like register diagnostics for fast design cycles and platform differentiation, simplifying VRD design and enabling fastest time-to-market (TTM) with “set-and-forget” methodology.

Data sheet
